Flexible Defect Inspection System for CMOS Image Sensor Applications

Published on October 12, 2009 at 8:46 PM

Today KLA-Tencor Corporation (NASDAQ:KLAC), the world's leading supplier of process control and yield management solutions for the semiconductor and related industries, extended its product offerings in the CMOS image sensor (CIS) market by announcing the 8900 defect inspection system. KLA-Tencor's new 8900 offers selectable illumination wavelengths, color-matched to CIS pixels; simultaneous brightfield and darkfield optical channels to enable capture of a wide variety of defect types; and adjustable sensitivity and throughput settings for cost-effective defect management from initial product development through volume production of color filter arrays (CFA).

KLA-Tencor's new 8900 high speed patterned-wafer defect inspection system represents a single-tool solution for image-sensor color filter and microlens development and production applications. (Photo: Business Wire)

Image sensors are devices that convert light into electrical signal, for use primarily in cameras. A color filter allows each pixel of the sensor to respond to a specific color—typically red, green or blue (RGB). The CFA is constructed in single-color, patterned layers, with one filter on top of each sensor pixel. Each pixel is capped with a micro-lens. As yield-limiting defects can occur at any step in the assembly process, the 8900's ability to inspect any of the filter or micro-lens layers can help reduce materials waste and cycle time.

An 8900 defect inspection system was recently installed at the first 300mm advanced CFA fab of Toppan Printing Company, Ltd., an industry leader in color filters. “State-of-the-art defect control is important to our ability to provide advanced color filters reliably,” said Keiichi Hara, Chief Manager, On-chip Color Filter Department, Kumamoto Plant of Toppan Electronics Products Co., Ltd. “The 8900 has improved our defect control capability and changed our strategy. Because the 8900 is sensitive to a wide range of defect types and has high throughput, it is performing all the defect inspections in the CFA process. This previously required multiple inspection tools. The 8900 can also automate the defect monitoring tasks that used to require manual inspection, making our cycle times shorter and more predictable.”

“Image sensor fabs have been using a combination of defect inspection systems, including manual inspection, to cover CFA process development, line monitoring, and incoming and outgoing quality control,” remarked Oreste Donzella, Vice President and General Manager of the SWIFT division at KLA-Tencor. “This strategy can lead to errors and inefficiencies. For example, manual inspection results have high variability. Even with automated systems, critical defect excursions can be missed because the results are difficult to compare among different systems. In developing the 8900, we leveraged KLA-Tencor's extensive experience in brightfield and darkfield micro and macro inspection to provide image sensor fabs with a single, flexible system to address the breadth of their CFA inspection requirements. We believe that the 8900 will allow fabs to improve resource allocation, increase the yield of their current products and accelerate delivery of their latest image sensors.”

Key features of the 8900 defect inspection system include:

  • Simultaneous brightfield and darkfield optical paths to capture a wide range of defect types in a single pass, such as micro-lens deformation; resist and fall-on defects; color contamination; large stains and striations;
  • Selectable LED inspection and review illumination spectrum matched to CIS filter colors;
  • Sensitivity consistent with requirements of advanced CIS roadmaps;
  • Throughput above 110 wafers per hour at production sensitivity, for 300mm semiconductor wafers;
  • Automated binning of defects by type;
  • Automated sensor pass/fail dispositioning; and
  • Automated color review for defect verification.

For more technical details about the 8900, please visit the product webpage: http://www.kla-tencor.com/patterned-wafer/8900.html.
