Park NX20 AFM is Available from LOT-QuantumDesign

Park's NX20 - the world's most accurate AFM for failure analysis (FA) and quality assurance (QA) - is available now from LOT-QuantumDesign.

As critical dimensions shrink and device complexity increases, the quality of your data is critical for the success of your research, analysis, and ultimately device yield.

The key to quality results is accuracy at the nanoscale. Park NX20, the world’s most accurate AFM for FA and QA, is the only high-end, large-sample AFM with non-contact mode for preserving tip sharpness.

Park NX20 provides the highest accuracy and repeatability for roughness measurements and defect review. Park NX20 offers the highest productivity and the industry’s lowest AFM lifecycle costs by dramatically lowering tip costs by extending tip lifetime. The result is a total AFM solution for FA and QA that meets accuracy, productivity and budgetary needs.

Accurate AFM Solutions for FA and Research Laboratories

  • Surface roughness measurements for media and substrates

Accurate and Reproducible Measurements for Better Productivity

  • Non-contact mode to preserve tip sharpness for surface roughness accuracy

Accurate AFM Topography with Low Noise Z Detector

  • Sample topography measured by industry leading low noise Z detector

Cost Savings with True Non-ContactTM Mode

  • 10 times or longer tip life during general purpose and defect imaging

About LOT Quantum Design

LOT QuantumDesign is a key supplier of nanotechnology solutions for research and industrial applications. Their range of products includes atomic force microscopes, scanning near field optical microscopes and confocal Raman microscopes.

LOT-QuantumDesign also specialises in providing instrumentation for several nanomanufacturing applications including dip pen nanolithography, thin film and surface analysis and nanoindentation.

LOTQuantumDesign offer a complete range of spectroscopy instrumentation including lights source, monochromators/spectrographs, solar simulators and filters.

About Park Systems

Park Systems is a leading manufacturer of atomic force microscopy (AFM) systems with a complete range of products for researchers and industry engineers in materials science, chemistry, physics, life sciences, semiconductor and data storage industries. Park’s products are used by over a thousand of institutions worldwide.

Park’s AFM features a unique patented set of technologies that yields the highest data accuracy at nanoscale resolution, superior productivity and ease of use, and lowest operating costs. Park Systems, Inc. is headquartered in Santa Clara, California with its global manufacturing, and R&D headquarters in Korea.
