PI Releases New Catalog on Piezo Mechanisms

PI (Physik Instrumente) L.P., a leading manufacturer of piezo ceramic actuators and precision motion-control equipment for semiconductor, bio-medical and nanotechnology applications -- has released a new catalog on Piezo Mechanisms.

The 400-page catalog presents PI’s complete spectrum of piezomechanic components and motion systems, from simple, direct actuators, to long-travel ceramic linear motors and complex multi-axis flexure guided nanopositioning stages. A separate section lists the latest digital control electronics.

The catalog also includes a tutorial on piezo design for positioning applications.

The catalog can be downloaded at: http://www.piezo.ws/pdf/Piezo_Mechanism_Cat10.pdf

Examples of Different Piezo Mechanisms to Solve Different Problems:

Direct Piezo Actuators: Z-Stacks, Shear (X, XY)

  • Highest Force (to 10,000 lbf)
  • Fastest Response: Microseconds to Milliseconds)
  • Short Travel Ranges: 2-100 µm

Piezo Flexure Lever Actuators

  • Longer Travel to 2 mm
  • Flexure Guiding System for Straight Motion
  • Response <1 msec

Ultrasonic Linear Motors

  • For High-Speed Automation and Microscopy
  • Long Travel (10s of millimeters to 100s of mm)
  • Fast:: to 500 mm/sec
  • Low Profile, Self Locking

PiezoWalk® Linear Motors

  • High Force (4 lb to 170 lb)
  • Compact, Self Locking
  • Long Travel (10s of millimeters)

Piezo Flexure Positioning Stages

  • Multi-Axis Motion, Highest Precision Class (Sub-Nanometer Feasible)
  • Applications in Semiconductor Technology, Nanotechnology, AFM, Super-Resolution Microscopy, etc.
