Micro Hardness Testers

According to ASTM E-384, microhardness testing specifies an allowable range of loads for testing with a diamond indenter. The resulting indentation is then recorded and converted to a hardness value. Typically loads are very light, ranging from a few grams to one or several kilograms. Since the test indentation is very small, microhardness testing is useful for a variety of applications such as testing very thin materials like foils or measuring individual microstructures.

Request a Quote for Micro Hardness Testers

If you'd like us to help you source a Quotation for Micro Hardness Testers please click here. Once submitted, we will try and place you in contact with a suitable Micro Hardness Testers supplier within 48 hours.

Featured Equipment

Nanomechanical Property Measurement System - NanoTest Vantage from Micro Materials

The new NanoTest Vantage system from Micro Materials Ltd offers a range of mechanical tests on the nano-scale, allowing the researcher to build a complete picture of material performance. The nanotest Vantage can characterise you samples using numerous techniques including nanoindentation, nano-impact and fatigue, nano-scratch and wear and nano-fretting.

Other Equipment

PICODENTOR HM500 from Fischer Instrumentation

The PICODENTOR HM500 is extremely suitable for the measurement of thinnest nanometer coatings. By evaluating the unload plot, one can draw conclusions about various material characteristics, such as the elastic indentation modulus EIT, according to the norm DIN EN ISO 14577.

Clemex CMT Automatic Microhardness Testing Machine

If your laboratory needs a robust solution for high throughput environments, then the Clemex CMT (automatic) solution is the path to take. Fully equipped with a state-of-the-art microhardness testing machine, ASTM E-384 and DIN/ISO 6507 compliant Clemex CMT Software, a high resolution camera, and a high performance computer, you can rest assured that you'll have all you need to extract fast, accurate and repeatable test results. Clemex CMT (automatic) performs tests in just 4 easy steps!

NANO Indenter® XP from SURFACE Systems+Technology GmbH

NANO Indenter XP systems provide a fast and reliable way to acquire mechanical data on the submicron scale. Incorporating the latest technologies for nanoindentation testing, NANO Indenter XP systems are complete test systems that feature a robust design to extend system life, the industry’s most powerful software, improved electronics, and a space-saving load frame. Through 23-bit electronics and very high data-sampling rates, NANO Indenter XP systems produce the most accurate data of any instrumented nanoindentation systems on the market. Each recorded data point is an average of 1000 separate measurements.

Leco LM100-Series Microindentation Hardness Testing System

Whether you are in a production facility or a research lab, LECO's LM-Series Microindentation Hardness Testing Systems offer you a wide variety of models (including analog and digital) with the advanced features you need at a price that is right.

Struers Duramin-1 and -2 Microhardness Testers

The Duramin microhardness testers from Struers allow you to perform Vickers and Knoop hardness tests reliably, reproducibly and accurately on metallic and non-metallic materials. The automated test sequence means that testing can be carried out efficiently, saving you valuable time.

CSM Instruments Micro Indenter (MHT)

The CSM Micro-Hardness Tester provides over three decades of normal force range and is therefore ideally suited to the mechanical characterization of hard coatings, thick soft coatings and bulk materials. It provides accurate and reproducible values for the hardness and elastic modulus of a various range of materials and coatings of considerably diverse thickness and hardness values.

Struers Duramin-5 Microhardness Testers

Duramin-5 is a PC controlled semiautomatic microhardness tester with automatic turret and touch pad or computer control of indent load and time. Duramin-5 is designed specifically for the laboratory or QC station that is looking to eliminate operator influence during indent measurement.

Struers Duramin-10 and -20 Microhardness Testers

The Duramin-10 /-20 are modular systems for computercontrolled microhardness testing based on the Duramin-1 /-2 and operating under Windows 2000 / XP Pro. The tester is available as a semi-automatic (Duramin-10) or a fully automatic (Duramin-20) model. A simply structured, graphical user interface enables the operator to use the control program after only a short period of familiarization. The sequence of measurement operations to be performed on a particular sample or set of samples can be pre-programmed and stored for future use.

Leco LM300-Series Microindentation Hardness Testing System

LECO's advanced Microindentation Testing Systems help you meet today's quality standards, as well as the challenges tomorrow's new materials present. LM300-Series offers durable membrane control panel with digital display and simple printing and data transfer capabilities.

FISCHERSCOPE HM2000 from Fischer Instrumentation

The FISCHERSCOPE® HM2000 is a computer-controlled measuring system for micro hardness testing and determination of material parameters according to ISO 14577. The HM2000 is available in three different versions - for manual, semi-automatic or automatic measurement of Martens Hardness according to ISO 14577 and DIN EN ISO 14577.

Leco LM700-Series Microindentation Hardness Testing System

LECO's advanced Microindentation Testing Systems help you meet today's quality standards, as well as the challenges tomorrow's new materials present. Leco LM700-Series offers advanced touch panel display, variable weight combinations, fracture toughness value (Kc), and holds up to three objectives from 2.5X to 100X.
