A new National Institute of
Standards and Technology (NIST) assay using a "glow or no glow"
technique may soon help the U.S. Department of Homeland Security (DHS) defend
the nation against a spectrum of biological weapons that could be used in a
terrorist attack. One very dangerous toxin on the list is ricin, a protein derived
from castor beans that is lethal in doses as small as 500 micrograms-about the
size of a grain of salt.
Microscopic photographs showing the level of fluorescence (green images on left) and the numbers of cells (blue images on right) at the time the cells were exposed to ricin (top row) and six hours later (bottom row). Note that the fluorescence has decreased (more black regions in the bottom left photo) while the cell count remains virtually the same. This shows that the NIST assay detects ricin even before significant cell death occurs. Credit: M. Halter, NIST
As part of its efforts to address the threat, DHS is working with NIST to create
a standardized ricin sample with a known potency. Such a standard is needed
both to check the accuracy of detection equipment, and, should an attack occur,
to confirm the success of decontamination procedures. A major step toward this
goal—the development of a rapid, reliable and precise assay of the potency
of a ricin sample—has now been achieved by NIST scientists.
As detailed in an article posted online this week in Assay and Drug Development
Technologies,* the new NIST assay uses a commercially available cell line genetically
engineered to produce large amounts of green fluorescent protein (GFP). Ricin
shuts down ribosomes—the protein manufacturing factories of a cell. Assay
cells exposed to the toxin will quickly stop synthesizing GFP. This, in turn,
will result in a measurable decrease in fluorescence—a drop that correlates
directly to the strength of the ricin present.
The NIST assay yields many advantages over traditional cytotoxicity measuring
systems, including: a highly sensitive response to ricin (as little as 1 nanogram
per milliliter) within six rather than 24 hours; detection of the toxin long
before significant cell death has occurred; results that are highly reproducible;
no need for the addition of any reagents; and the flexibility to measure the
potency of other ribosome inhibitors, even nanoparticles, with the same precision
as ricin.
