QMF and SPTS Achieve Epitaxial Growth of 3C SiC Films on 300mm Silicon Wafers

Published on May 30, 2013 at 6:50 AM

The Queensland Micro and Nanotechnology Facility (QMF) of Griffith University and industry partner SPTS Technologies, a supplier of advanced wafer processing solutions for the global semiconductor industry and related markets, have announced epitaxial growth of 3C silicon carbide (SiC) films on 300mm silicon wafers.

This breakthrough is the result of over 10 years research at QMF on low temperature SiC deposition on silicon and the joint development by QMF and SPTS of a commercial reactor to extend the epitaxial growth process to commercial scale production of SiC coated silicon wafers.

The ultimate target of the joint project is to provide a cost-effective buffer material to enable fabrication of gallium nitride (GaN) devices on silicon substrates. Fabricating GaN light emitting diodes (LEDs) and power devices on large diameter silicon wafers is viewed as a path to improve performance and reduce cost, thereby increasing commercial acceptance of these devices; however, existing buffer layers used to bridge the large thermal and lattice mismatch between silicon and GaN are costly and not completely effective for large scale production.

A 3C-SiC film provides an effective buffer layer lattice-matched for GaN growth on silicon, as well as an impervious barrier to prevent silicon from diffusing into GaN, of particular concern for power devices. Initial estimates are that the new SiC on silicon coating process in volume production would add no more than $25-35 to the cost of a silicon wafer, substantially increasing the appeal of silicon as a substrate for LEDs and GaN power devices.

“We believe we are the first in the world to grow 3C-SiC epitaxially on 300mm silicon wafers, which means following the same crystal structure as the silicon crystal substrate,” said Alan Iacopi, QMF Director of Operations. “The reactor development project with SPTS has allowed the QMF R&D process to be extended from small wafers up to 300mm wafers with semiconductor industry specifications; in fact, we have already achieved SiC film thickness uniformities of around 1% on 300mm wafers using the new reactor.”

“SPTS is excited to be a partner in this project, as we see the QMF SiC technology as a potential breakthrough in reducing the cost of LEDs and improving the performance of GaN power devices,” according to William Johnson, President and CEO of SPTS. “Based on our extensive background in vertical furnace technology, the new reactor has been designed for high temperature vacuum processing of batch loads of 150mm to 300mm wafers, with process automation suitable for commercial application. There are a number of buffer and template wafer suppliers offering alternative solutions; however, we see a strong business case for device manufacturers adopting the QMF/SPTS SiC solution to optimize process and control substrate costs.”

Added Mr Iacopi, “The Griffith University and SPTS partnership has far reaching implications in terms of demonstrating how Australian research entities (like QMF) can collaborate with international industry to advance frontier technologies and bring industrial benefit to Queensland. We have all the ingredients to develop a high tech economy in Queensland, including technically leading Universities, the Australian National Fabrication Facility infrastructure, entrepreneurial spirit, and start-up company investment support.”

About Griffith University Queensland Micro and Nanotechnology Centre

The Queensland Micro- and Nanotechnology Centre is a science and engineering research centre based at Griffith University. The Centre brings together researchers with expertise in materials development, sensing, microelectronic engineering and the fundamental theory of condensed matter. The Queensland Microtechnology Facility, within the QMNC, is focused on leading SiC on Si technology to commercialisation. Funded by Queensland State Government and Australia's National Fabrication Facility, it houses a large silicon wafer fabrication processing capability and enables research and development of SiC on Si material for mechanical and semiconductor devices.

Source: http://www.spts.com/
