Modeling Wing Nanostructures to Improve Solar Technologies

Harnessing renewable energy has been a prominent strategy to promote environmental conservation. Butterfly wings exhibit many unique properties, such as their striking wing coloration, light absorption mechanisms, and responses to various stimuli. For many years researchers have tried to replicate the intricate features of nature to develop artificial functional materials such as sensors, robotics, photovoltaics, and many more.

butterfly, wings, solar energy

Image Credit: KRIACHKO OLEKSII/Shutterstock.com

How have Butterfly Wings Inspired Scientists?

Butterflies are lepidopteran insects that have always intrigued researchers. Initially, scientists were more interested in the biological characteristics of a butterfly; for instance, they pointed out that chitin is the main component of butterfly wing scales. Some of the most intriguing characteristic features of these scales include interchangeable high and low refractive indices and their dimension ranges of a few hundred nanometers.

Butterfly wing comprises one bilayer scale of fused cover scales in the upper layer and small fused ground scales in the lower layer. Numerous nanostructured wing scales are arranged in an uneven, overlapping ordering, ridge ornamentation, and have periodicities between 140 and 2000 nm.

Microarchitecture of the wings revealed that each scale has a distinct shape, parallel or inclined arrangement, pigmented or unpigmented, concave or hemispherical curvature, and porous lumen. These arrangements are responsible for visible light scattering.

The micro/nanoarchitecture of the butterfly wings has inspired the development of efficient sensors and various energy applications. Energy harnessing applications predominantly rely on the wing's nanoscale properties that involve refractive index responsiveness and light-trapping mechanisms.

Solar Energy and Butterfly Wings

At present, there is a high demand for renewable sources of energy, such as solar. Despite being renewable, solar energy has not yet gained much popularity owing to some significant constraints that include its high cost.

Once harvested, this source has to be immediately used as storing solar power requires installing large and expensive batteries. Additionally, solar energy is inconsistent and can be used only during the daytime.

Numerous technologies associated with harvesting solar energy are available, which have not proved to be quite efficient owing to their low energy conversion ability, decreased quantum conversion outputs, and low optical absorption coefficients. Therefore, scientists continue to explore more efficient ways to harness energy from renewable sources.

One of these avenues has led scientists to take inspiration from the nanostructures of butterfly wings.

An example of the technologies associated with harvesting energy from solar light is by using Solar photovoltaic (Solar PV), which converts sunlight directly into electricity using solar PV cells. The performance of photovoltaic cells is dependent on the surface of the nanomaterial used, e.g., titanium dioxide.

Researchers have developed a second-generation solar PV cell, which is a thin-film solar cell comprised of layers of micron-think photon-absorbing materials deposited on a flexible substrate.

Although this technology is cost-effective, it is not as efficient as regular solar PV cells. A way to overcome this shortcoming has been explored by studying how a butterfly's wings absorb sunlight.

Some of the unique properties of butterfly wings that have helped improve solar technologies are their large surface area, porous architectures, stimuli responsiveness, and light manipulation.

butterfly, nanostructures, wings

Image Credit: Matee Nuserm/Shutterstock.com

A group of researchers at the Karlsruhe Institute of Technology (KIT) have recently reported the development of solar cells based on the nanostructure of butterfly wings, which has increased the rate of light absorption by up to 200%.

The "common rose" butterfly or Pachliopta aristolochiae, is commonly found in South and Southeast Asia. This species of butterfly has predominantly black wings with some white and red spots.

The scales present on the wings not only provide protection but also absorb sunlight and turn it into heat while the scales capture the solar energy over a wide range of angles and wavelengths and maintain the body temperature.

Scientists studied the wings of this butterfly under an electron microscope and developed a three-dimensional model of the nanostructure of the wings. They found that the wings were covered with randomly spaced holes of about less than one micrometer wide, making the wings lighter and also scattering the sunlight striking them, which enables maximum absorption of sunlight throughout the day.

Thin-Films Inspired by Wings

Using this concept, the research team developed a similar thin-film structure comprised of a layer of tiny holes on top of a silicon base. Interestingly, they found this material could roughly absorb twice as much light as other designs.

Scientists are optimistic that this design can improve the efficiency of the thin-film cells significantly and would greatly impact the solar industry.

Comparative studies have considered the development of organic solar cells using silver butterfly wings architecture. These solar cells comprise a one-dimensional periodic array of plasmonic butterfly-wing shaped nanostructures which increase light absorption, scattering, and trapping of the incident optical radiation at multiple wavelengths. The elevated light scattering promotes increased path length of light and improved light intensity to the overall surface area.

Scientists believe that these advancements could bring about a major change in the utilization of solar energy. An increase in the use of this energy could help protect the environment from various forms of pollution and resist rapid climatic changes.

Continue reading: Can this Novel Nanocomposite Improve Solar Energy Performance?

References and Further Reading

Osotsi, I. M. et al. (2021) Butterfly wing architectures inspire sensor and energy applications, National Science Review. 8(3). Available at: https://doi.org/10.1093/nsr/nwaa107

Kumar, K. et al. (2019) Light trapping plasmonic butterfly-wing-shaped nanostructures for enhanced absorption and efficiency in organic solar cells. Journal of Optical Society of America B. 36, pp. 978-990. Available at: https://doi.org/10.1364/JOSAB.36.000978

McCur, D. (2017) Butterfly Wings Could Lead the Way to More Efficient Solar Panels. [Online] Available at: https://www.renewableenergymagazine.com/pv_solar/butterfly-wings-could-lead-the-way-to-20171020

Siddique, H.R. et al. (2017) Bioinspired phase-separated disordered nanostructures for thin photovoltaic absorbers. Science Advances. 3(10). Available at: https://doi.org/10.1126/sciadv.1700232
