Magnetic Fluids and Magnetic Media Processing Methods and Applications that Use Nanomaterials

Magnetic fluids or ferrofluids are stable colloidal suspensions of magnetic metal nanoparticles in a carrier liquid. To maintain suspension, the particles are coated with a surface active layer. The carrier liquid can be a hydrocarbon, ester, perfluorether, water, etc. Properties of nanomagnetic particles, films and bulk materials include exchange coupling, tunneling magnetoresistance, giant magnetoresistance, single domain behavior, and superparamagnetism. Magnetite based magnetic fluids do not have sufficient magnetic properties for many applications. Colloidal nanosized metallic Fe, Co or Fe/Co alloys like those offered by Strem do posses ideal properties.


Magnetic fluids are attractive in separation applications because the reactivity of the particles can be tailored by modifying their surface coatings, they afford very high surface areas without the use of porous absorbents, and they can be recovered for reuse.

Using Magnetic Nanoparticles in Nanocatalysts - Processing Methods and Benefits

Nanocatalysts containing magnetic nanoparticles are being developed. Silica and carbon are utilized to maintain the stability of the nanoparticles under reaction conditions. Functionalized surfaces on the nanoparticles include immobilizing sites for catalytically active species such as nanometal particles, enzymes, and homogenous catalysts. The catalysts are easily separated by utilizing the magnetic interaction between the magnetic nanoparticle and an external applied magnetic field. These hybrid catalysts offer the advantages of homogeneous and heterogeneous catalysis combined

Using Magnetic Nanomaterials in Filters and to Remove Sulfur Compounds from Hydrocarbon Fuels

Magnetic nanomaterials have also been used in filters to remove selected impurities from various types of fluids. The separation of organic contaminants such as polyaromatic hydrocarbons from water and the removal of sulfur compounds from hydrocarbon fuels, are also being investigated with magnetic fluids.

Current Research into Biochemical Reactions Using Magnetic Nanoparticles

In biochemical reactions, magnetic nanoparticles are being investigated as a means to aid in the separation and recovery of target biomolecules such as DNA, RNA, and proteins. Non-ferrous metals can be rapidly recovered from solid wastes using sink-float separation, which utilized the magnetic fluid as a coating on the materials. Metals of different densities can be separated by controlling the field gradient, which levitates the materials.

Magnetic Media

Magnetic nanoparticles have significant potential for increasing magnetic storage capabilities. Cobalt and Pt/Co bimetallic nanoparticles are being investigated as magnetic storage devices. Researchers are studying core-shell cobalt nanoparticles embedded in an anti-ferromagnetic matrix. Cobalt nanoparticles have also been found to self-assemble into ‘nanorings’ that can store magnetic information at room temperature. These magnetic rings are being considered as memory elements in devices for long-term data storage and magnetic random-access memory (MRAM).

This diagram shows a magnetic hard disk and the schematic illustration of the recorded bits supported by an array of ferromagnetic dots.

Figure 1. A magnetic hard disk and the schematic illustration of the recorded bits supported by an array of ferromagnetic dots.

How Magnetic Cobalt Nanocrystals Can Improve Magnetic Random-Access Memory (MRAM) Systems

MRAM systems are currently severely under-damped systems. Just a few monolayers of magnetic cobalt nanocrystals deposited on the surface of the magnetic layer in an MRAM device have been found to provide a tripling of the dampening effect. In addition, a 2-2-3 fold enhancement of the magnetic field can be achieved in an MRAM device when a superparamagnetic nanoparticle layer is used in place of the continuous liner. As a result, a third of the current can be used to obtain the same magnetic field as before. Alternatively, the same amount of current can be used to obtain a much more thermally stable system.

Industry Applications for Polystyrene Films Containing Gold Nanoparticles

Polystyrene films containing gold nanoparticles have been found to store a charge and act as organic memory devices. The polystyrene base, which is carried in a liquid, can be applied through spray, paint, or print technology. 3-D arrays can also be constructed for high density storage and could have applications in digital memory chips for computers, digital cameras, and cell phones. The goal of other researchers is to have each nanomagnetic particle support one bit of digital information.

Industrial Applications for Magnetic Fluids

Industrial applications for magnetic fluids include seals, dampers, and moving coil loud speakers. In seals, the ferrofluid acts as a magnetic O-ring and provides hermetic sealing with zero leakage. Because the fluid is also lubricating, minimal wear occurs as well. Seals based on magnetic fluids have been developed for vacuum systems, gas-air media, and liquids (water, oil, and chemically active media). They find use in high speed computer disk drives, rotating joints in clean rooms, and in industrial applications where control of volatile emissions and protection of sensitive environments is important.

Using Magnetic Fluids as Dampers - Processing Methods

Magnetic fluids can change their apparent viscosity in proportion to the strength of an applied magnetic field. Therefore, the viscosity can be controlled dynamically, which allows for active damping. Large amounts of mechanical power can be controlled with a small amount of electrical power, making this method of vibration control much more efficient than traditional systems. It is possible to adjust the stiffness thousands of times per second. As dampers, magnetic fluids are highly efficient over a wide frequency and temperature range. They are used to dampen automotive devices, space structures, wing oscillations in aircraft, protect devices and some buildings from vibrational damage, and to improve comfort during transport.

Using Magnetic Fluids in Moving Coil Loudspeakers - Processes and Benefits

In a moving coil loudspeaker, the magnetic fluid conducts heat away from the voice coil, keeps the voice coil concentric with the magnet, and passively dampens movement of the cone. The magnetic fluid is placed in what is normally the air gap around the voice coil. Advantages of using magnetic fluids in moving coil loudspeakers include increased power handling, a smooth frequency response curve, and reduced distortion.

List of Nanomaterials that Strem Chemicals Can Supply to All Types of Industry

Numerous other potential applications exist for magnetic nanomaterials from Strem. Areas currently under investigation include non-destructive testing, finishing polishing, domain observation, telecommunications, magnetic inks, robotics, automotive, surface analysis, and medical/pharmaceutical such as targeted drug delivery, diagnostics, and biosensors. A listing of specific including metal nanoclusters, metal nanocolloids (organosols and hydrosols), metal nanopowders, metal nanoparticles, and magnetic fluids offered by Strem is available upon request or via our website. Application sheets discussing the potential use of these products in the medical and pharmaceutical, defense and security, chemical, automotive, and energy fields, and as magnetic fluids, can also be obtained from Strem. More information is also available in the form of a reference sheet listing literature source materials.

This information has been sourced, reviewed and adapted from materials provided by Strem Chemicals.

For more information on this source, please visit Strem Chemicals.
