These five trends paint a picture of a dynamic future in nanophotonics. Spanning adaptive structures, biosensing, AI, and more, the field is no longer simply an exploratory science, but a cutting-edge discipline.
Image Credit: Heinrich Delasiava/Shutterstock.com
What is Nanophotonics and How Does It Work?
Nanophotonics, also known as nano-optics, is the study and manipulation of light at the nanoscale. It examines how photons interact with nanostructures and materials, enabling control over light-matter interactions beyond the limits of classical optics.1
This is achieved by designing nanostructures, often metallic or dielectric, that support unique optical resonances such as surface plasmons or Mie resonances.
These effects concentrate electromagnetic fields into minute volumes, intensifying light-matter interactions and enabling functionalities such as enhanced absorption, emission, and nonlinear effects.
Here, we discuss the top five emerging trends in nanophotonics and how they will advance areas beyond optics, from healthcare to 3D printing.
Get all the details: Grab your PDF here!
Active and Tunable Nanophotonics
One major trend in nanophotonics is the development of actively tunable or reconfigurable devices. In these devices, the optical response can be altered post-fabrication by external stimuli, such as electrical bias, temperature, phase-change materials, or optomechanical actuation.1
A recent study in Nanophotonics reported the design of an optical Kerr effect in multilayer hyperbolic metamaterials, enabling nonlinear control of light within a nanostructured stack.2
The work is significant in its method for designing multilayer metamaterials with strong third-order optical nonlinearities, meaning light can be more easily controlled for powerful light-based technologies.
Another article reported in the same issue presents a tiny Drude scatterer to model a coherent emitter in a nanophotonic environment, thereby enabling tailored emission by embedding tunable elements in the structure.3
Their scattering approach reproduced 'textbook' coherent scattering, not possible with typical methods. In addition, the emitter's linewidth produced adapts to the surrounding optical energy density.
These works demonstrate that by combining material engineering with structural design, optical responses can be dynamically controlled, opening the door to modulators, switches, adaptive optics, and quantum state control at the nanoscale.
For both industry and research, this demonstrates that nanophotonic components can become more versatile and integrated into systems that adapt to changing conditions.
For example, in optical communications, one might realize modulators based on nanostructures. In sensors, one might adjust sensitivity dynamically. In displays or adaptive optics, one might tune the response in real-time.1
Image Credit: robow/Shhutterstock.com
Biosensing and Healthcare Applications
Nanophotonics is no longer solely about fundamental light-matter interactions. It directly impacts clinical diagnostics, environmental monitoring, and beyond.
Key challenges in using nanophotonics in these areas include integration, reproducibility, cost-effectiveness, and biocompatibility. However, the adoption of this field across disciplines is advancing.4
A recent review on nanophotonic biosensors highlights how phase-driven, resonant dielectric, plasmonic, and surface-enhanced spectroscopies and evanescent field sensors are being optimized for real-world biological and environmental detection challenges (ultrasensitive detection of biomarkers and pathogens).4
Nanophotonic platforms can enhance biosensing capabilities by improving sensitivity and specificity in detecting biomolecules, such as nucleic acids (DNA and RNA).
Techniques such as non-destructive, reference-free grazing incidence X-ray fluorescence (RF-GIXRF) utilize nanophotonic enhancements to analyze molecular arrangement densities in self-assembled monolayers, which are crucial for next-generation biosensors.
These innovations enable rapid and cost-effective biomedical diagnostics with potential clinical applications in detecting diseases at early stages.5
Learn all about nanosensors in life sciences, here!
Large-Area Fabrication, Additive Manufacturing & Scalability
A persistent challenge in nanophotonics is scalability, fabricating nanoscale features over large areas, at a low cost, high throughput, and high yield.
Increasingly, research is turning to nanoimprinting, roll-to-roll manufacturing, additive manufacturing, and hybrid top-down/bottom-up methods to address scale and manufacturability.
In early 2025, Chou Chau identified large-area nanoimprinting and additive manufacturing for nanophotonics as an emerging application.4
In the review, Chou Chau describes how roll-to-roll imprinting can produce metre-scale nanophotonic films (e.g., diffractive waveplates, holograms) using continuous nano-embossing and coating.4
Even more recently, an article in Photonics emphasized the design of nanophotonic devices that take into account realistic fabrication constraints, highlighting the move toward practical, scalable device design.3
On-Chip Photonic Integration
Among these trends, a defining direction for nanophotonics is on-chip photonic integration, which brings nanoscale optical components onto chips to complement or replace electronic systems.
By integrating lasers, modulators, detectors, and waveguides on a single platform, researchers aim to achieve high-speed, low-power optical interconnects for data centres, computing, and sensing applications.
Recent reviews have demonstrated the successful heterogeneous integration of III–V semiconductor lasers onto silicon photonic chips, marking a major milestone toward scalable, CMOS-compatible photonics.
Nanophotonic elements such as plasmonic waveguides and high-index dielectric circuits are being designed to route and confine light efficiently at chip-scale dimensions.6
The potential payoff is enormous. Photonic computing and communication systems that combine the speed of light with the compactness of nanotechnology.
The remaining barriers involve managing fabrication tolerances, propagation losses, and thermal stability at the nanoscale.
Machine Learning and AI-Driven Design
By combining 2D materials with machine learning (ML), scientists are revolutionizing the design and optimization of nanophotonic devices.
Materials like graphene, MoS2, and hBN exhibit remarkable optical tunability, making them ideal for hybrid nanostructures that combine plasmonic and dielectric elements.7
Recent research has revealed how hybrid architectures, which combine metals, dielectrics, and 2D materials, can overcome the limitations of individual materials, such as metallic losses or narrow bandwidths. Moreover, machine learning assisted inverse design is emerging as a transformative tool.
Another Nanophotonics paper showed that by training algorithms to predict or optimize nanostructure geometries, researchers can rapidly discover designs that achieve specific optical responses without the need for exhaustive simulations.8
This synergy between advanced materials and computational design heralds a new era of intelligent photonic engineering, though translating ML-generated designs into manufacturable devices remains a key challenge.
Conclusion
As nanophotonics continues to mature and evolve, these five clear trends point towards a future where these advances reshape sensing, computation, and communication.
The field has shifted away from preliminary investigations and initial reviews to a concrete technology that is already being used outside of research. Nanoscale light control could one day become a key player in everyday systems.
References and Further Reading
- Fan K, Averitt RD, Padilla WJ. Active and tunable nanophotonic metamaterials. Nanophotonics. 2022;11(17):3769-3803. https://doi.org/10.1515/nanoph-2022-0188
- Genchi D, Dodici F, Cesca T, Mattei G. Design of optical Kerr effect in multilayer hyperbolic metamaterials. 2024;13(25):4523-4536. https://doi.org/10.1515/nanoph-2024-0169
- Binkowski F, Burger S, Kewes G. A tiny Drude scatterer can accurately model a coherent emitter in nanophotonics. 2024;13(25):4537-4543. https://doi.org/10.1515/nanoph-2024-0170
- Chou Chau Y-F. Nanophotonic Materials and Devices: Recent Advances and Emerging Applications. Micromachines. 2025;16(8):933. https://doi.org/10.3390/mi16080933
- Michalowska A, Kudelski A. Applications of surface enhanced Raman scattering (SERS) spectroscopy for detection of nucleic acids. Nanophotonics. 2024;13(25):4577-4603. https://doi.org/10.1515/nanoph-2024-0230
- Xue Y, Li J, Wang Y, et al. In-Plane 1.5 µm Distributed Feedback Lasers Selectively Grown on (001) SOI. Laser & Photonics Reviews. 2024;18(1):2300549. https://doi.org/10.1002/lpor.202300549
- Ryu B, Wang L, Pu H, Chan MKY, Chen J. Understanding, discovery, and synthesis of 2D materials enabled by machine learning. Chemical Society Reviews. 2022;51(6):1899-1925. https://doi.org/10.1039/D1CS00503K
- Zhang, H., Kang, L., Campbell, S. D., & Werner, D. H. (2025). Chat to chip: large language model based design of arbitrarily shaped metasurfaces. Nanophotonics (Berlin, Germany), 14(22), 3625–3633. https://doi.org/10.1515/nanoph-2025-0343
