Researchers at Lomonosov Moscow State University Use Nanoparticle Tracking Analysis for Vaccine Characterization

NanoSight reports on how Nanoparticle Tracking Analysis, NTA, is used for vaccine characterization and standardization in the virology research group of Dr Nikolai Nikitin at Lomonosov Moscow State University.

Dr Nikolai Nikitin with his Junior Researcher, Ekaterina Trifonova with the NS500 system in the Department of Virology, MSU

The MSU Department of Virology headed by Professor Joseph Atabekov is studying the in vitro assembly of compositions, consisting of artificial plant virus particles and antigens, potentially attractive for vaccines development. Artificial plant virus particles are spherical particles (SPs) generated by thermal denaturation and structural remodelling of helical plant tobacco mosaic virus, a rod-shaped virus with a diameter of 18 nm and a modal length of 300 nm. It has been found that upon thermal denaturation of TMV, viral RNA is released and becomes degraded whereas viral coated protein is assembled into spherical particles. The size of SPs depends on the initial TMV concentration and particles from 50 to 800 nm may be obtained. The group of Professor Olga Karpova has shown that SPs based on TMV are stable and may adsorb a diversity of proteins. Thus, SPs represent a new type of biogenic nanoplatform attractive for binding antigens and antigenic determinants of different pathogens.

Describing the choice of NTA for this work, Dr Nikitin says "It permits us to analyze and control the size, state of aggregation and concentration of artificial plant virus particles and small spherical plant and animal viruses. Furthermore, NTA allows us to see the formation of immunogenic complexes (candidate vaccines) by using the indirect immunofluorescence or immunogold staining methods. The technique provides us with the opportunity to obtain simultaneous information concerning nanoparticle size, state of aggregation, concentration and antigenic specificity in liquid. This is particularly important for vaccine characterization and standardization."

Continuing on the benefits of NTA over other characterization methods, Dr Nikitin says "Previously, we had used transmission electron microscopy (TEM) and dynamic light scattering (DLS) for sizing SPs, isometric viruses and virus-like particles. To detect the formation of immunogenic complexes (candidate vaccines) we use immunogold TEM and immunofluorescence microscopy. For us, the main advantage of NTA over these microscopic methods is that there is no need to fix and dry the object on a supporting film which could lead to morphological deformations and aggregation of nanoparticles. NTA provides the means for analysis of samples in liquid in real-time. DLS is also available for measuring the size of nanoparticles in liquids. However, particle aggregation and any contamination of samples will lead to incorrect results. The correct size of the particles can be obtained by DLS only in the absence of aggregation and polydispersity of sample. In addition, DLS cannot estimate the number of particles per unit volume and cannot detect the retention of particles antigenic properties. NTA does not have these problems as it makes measurements particle by particle."

To find out about the company and to learn more about particle characterization using NanoSight's unique nanoparticle tracking analysis solutions, visit and register to receive the next issue of NanoTrail, the company's electronic newsletter.
