Making Spider Silk Significantly More Break-Resistant and Ductile

Spiderman would definitely have an easier time of things with this spider silk - for example, if he had to stop a getaway car moving off at 100 kilometres per hour. A five-millimetre-thick thread would do the job from a distance of 20 metres - assuming it had been treated by a team of researchers from the Max Planck Institute of Microstructure Physics. The same task would require a finger-thick thread of untreated spider silk and a steel rod as thick as a forearm. The Max Planck scientists strengthen the natural material by infiltrating it with metal ions. It may also be possible to strengthen other natural and synthetic fibres in this way. (Science, April 24, 2009)

Endurance test for spider silk: in many ways, spider silk - here the picture of a garden cross spider in its web- is stronger than a metal wire of the same thickness. After researchers at the Max Planck Institute for Microstructure Physics infiltrated spider silk with metal ions, a double-strand of silk can support the weight of a cube of 27.5 grams, three times more than an untreated strand. Image: Max-Planck-Institut für Mikrostrukturphysik

Even if it has nothing to do with the elevator for the ISS space station, the vision being pursued by NASA in its dream factory, a steel cable that pulls the elevator in a skyscraper on the scale of the Empire State Building, has to carry almost as much in its own weight as it does in the actual elevator cabin. And the higher the buildings, the thicker and heavier the cables become. A material that is as strong as the spider silk infiltrated with metal ions produced by the Max Planck Institute of Microstructure Physics could help with this application.

The fact that spider silk treated with metal ions does not break under enormous tension is just one of the advantages it has to offer: "It can be expanded twice as much as natural spider silk," says Mato Knez, who is heading the research at the Max Planck Institute. As the treated material withstands high levels of tension and strain, it absorbs ten times more energy than the natural material before it breaks. Thus, it is particularly suitable for braking at full speed or braking free fall, for example in the case of a mountain climber.

Materials with such properties could also be used in aircraft and vehicle construction or in space technology, generally for any application that requires light, strong, and flexible materials. "Our work promises great potential in terms of practical applications, as many other biomaterials can be made more break-resistant and ductile using our method," explains Mato Knez. There is one important precondition, however: the natural materials must contain proteins as their main component. For example, Knez and his colleagues have already used the metal infiltration process to strengthen fibres made of the protein collagen which composes bones and skins in human body.

As the researchers discovered, the strengthening treatment for spider silk and other protein fibres only works when the metal ions can penetrate into the fibres. To achieve this, they adapted the atomic layer deposition (ALD) technique. This method is usually used to deposit individual layers of metal oxides on the surface of materials by exposing them to water vapour and a volatile compound comprising metal and organic appendages in rapid succession. Up to a few hundred of such gas pulses stream into the material and coat it with a more or less thick layer of oxide. "Because each pulse only lasts fractions of a second, the metal does not penetrate the material, however," explains Mato Knez: "Therefore, we adapted the equipment so that we could extend an individual pulse to a duration of up to 40 seconds."

In order to make it clear that the process involved here no longer involves a coating process as is the case in standard ALD, the researchers refer to the modified technique as "Multiple Pulsed Vapour Phase Infiltration" or MPI. By doing this, they wish to avoid any possible confusion in the future. "Actually, it was rather difficult for us to make it clear to colleagues that we are infiltrating materials using a process that previously was only used for coating."

The researchers were able to detect under the transmission electron microscope that metal atoms from the vapour phase could also creep into the interior of the spider silk. For these tests, a scientist from the Martin Luther University Halle-Wittenberg cut 90-nanometer-thin slices of the spider silk. The microscopic images did not explain, however, why the metal atoms increase the strength of the protein fibres. "Up to now, we only have a few pointers about this," says Mato Knez: for example, from NMR measurements, which the researchers at the University of Halle made of spider silks infiltrated with aluminium.

"This would indicate that the aluminium is present in a compound other than a typical aluminium oxide," says Knez. And he has a good idea which compound it is: "We assume that the metal atoms bind the protein molecules to each other." Hydrogen atoms usually form bridges between the molecules which, however, break far more easily than the strong compounds made using metal atoms. Thus, it becomes plausible for metal-infiltrated spider silk to withstand more weight than the natural version. The better ductility can also be explained in this way. A thread of spider silk can be extended in length because its protein fibres run together like tangled wool in areas referred to as amorphous. In other locations, they arrange themselves in an orderly line like a neat ball of wool. "In these crystalline areas, the hydrogen bridges are probably also replaced by metal ions," says Mato Knez. Consequently, their order dissolves, the amorphous areas increase and with them the ductility.

Despite its dramatically improved properties, metal-infiltrated spider silk is unlikely to be used to reinforce either fenders or aircraft wings in the future. "It would probably be more or less impossible to obtain large volumes of natural spider silk," says Knez. The insects are very difficult to keep and are not particularly productive when it comes to spinning their silk. Nonetheless, Knez is convinced of the practical use of this power thrust for materials: "We are pretty certain that we will also be able to improve the properties of synthetic materials that imitate natural ones using our process."
