Biodegradable Nanosized Particles to Deliver Sustained-Release Medication Cargo

Johns Hopkins University researchers have created biodegradable nanosized particles that can easily slip through the body's sticky and viscous mucus secretions to deliver a sustained-release medication cargo. The researchers say that these nanoparticles, which degrade over time into harmless components, could one day carry life-saving drugs to patients suffering from dozens of health conditions, including diseases of the eye, lung, gut or female reproductive tract.

Individual biodegradable nanoparticle developed by the Justin Hanes Lab at Johns Hopkins University (shown here at microscale for easier imaging) displaying polymer coating as a red fluorescent glow. Hanes' biodegradable nanoparticles have the ability to penetrate mucus barriers in the body to deliver drugs. (Photo by Jie Fu/JHU)

The mucus-penetrating biodegradable nanoparticles were developed by an interdisciplinary team led by Justin Hanes, a professor of chemical and biomolecular engineering in Johns Hopkins' Whiting School of Engineering*. The team's work was reported recently in the Proceedings of the National Academy of Sciences. Hanes' collaborators included cystic fibrosis expert Pamela Zeitlin, a professor of pediatrics at the Johns Hopkins School of Medicine and director of Pediatric Pulmonary Medicine at Johns Hopkins Children's Center.

These nanoparticles, Zeitlin said, could be an ideal means of delivering drugs to people with cystic fibrosis, a disease that kills children and adults by altering the mucus barriers in the lung and gut. "Cystic fibrosis mucus is notoriously thick and sticky and represents a huge barrier to aerosolized drug delivery," she said. "In our study, the nanoparticles were engineered to travel through cystic fibrosis mucus at a much greater velocity than ever before, thereby improving drug delivery. This work is critically important to moving forward with the next generation of small molecule- and gene-based therapies."

Beyond their potential applications for cystic fibrosis patients, the nanoparticles also could be used to help treat disorders such as lung and cervical cancer and inflammation of the sinuses, eyes, lungs and gastrointestinal tract, said Benjamin C. Tang, lead author of the journal article and a postdoctoral fellow in the Department of Chemical and Biomolecular Engineering. "Chemotherapy is typically given to the whole body and has many undesired side effects," he said. "If drugs are encapsulated in these nanoparticles and inhaled directly into the lungs of lung cancer patients, drugs may reach lung tumors more effectively and improved outcomes may be achieved, especially for patients diagnosed with early stage non-small cell lung cancer."

"If drugs are encapsulated in these nanoparticles and inhaled directly into the lungs of lung cancer patients, drugs may reach lung tumors more effectively and improved outcomes may be achieved, especially for patients diagnosed with early stage non-small cell lung cancer." ~ Ben Tang

In the lungs, eyes, gastrointestinal tract and other areas, the human body produces layers of mucus to protect sensitive tissue. But an undesirable side effect is that these mucus barriers can also keep helpful medications away.

In proof-of-concept experiments, previous research teams led by Hanes earlier demonstrated that latex particles coated with polyethylene glycol could slip past mucus coatings. But latex particles are not a practical material for delivering medication to human patients because they are not broken down by the body. In the new study, the researchers described how they took an important step forward in making new particles that biodegrade into harmless components while delivering their drug payload over time.

"The major advance here is that we were able to make biodegradable nanoparticles that can rapidly penetrate thick and sticky mucus secretions, and that these particles can transport a wide range of therapeutic molecules, from small molecules such as chemotherapeutics and steroids to macromolecules such as proteins and nucleic acids," Hanes said. "Previously, we could not get these kinds of sustained-release treatments through the body's sticky mucus layers effectively."

The new biodegradable particles comprise two parts made of molecules routinely used in existing medications. An inner core, composed largely of polysebacic acid, or PSA, traps therapeutic agents inside. A particularly dense outer coating of polyethylene glycol, or PEG, molecules, which are linked to PSA, allows a particle to move through mucus nearly as easily as if it were moving through water and also permits the drug to remain in contact with affected tissues for an extended period of time.

In Hanes' previous studies with mucus-penetrating particles, latex particles could be effectively coated with PEG but could not release drugs or biodegrade. Unlike latex, however, PSA can degrade into naturally occurring molecules that are broken down and flushed away by the body through the kidney, for example. As the particles break down, the drugs loaded inside are released.

This property of PSA enables the sustained release of drugs, said Samuel Lai, assistant research professor in the Department of Chemical and Biomolecular Engineering, while designing them for mucus penetration allows them to more readily reach inaccessible tissues.

Jie Fu, an assistant research professor, also from the Department of Chemical and Biomolecular Engineering, said, "As it degrades, the PSA comes off along with the drug over a controlled amount of time that can reach days to weeks."

PEG acts as a shield to protect the particles from interacting with proteins in mucus that would cause them to be cleared before releasing their contents. In a related research report, the group showed that the particles can efficiently encapsulate several chemotherapeutics, and that a single dose of drug-loaded particles was able to limit tumor growth in a mouse model of lung cancer for up to 20 days.

Hanes, Zeitlin, Lai and Fu are all affiliated with the Johns Hopkins Institute for NanoBioTechnology. Other authors on the paper are Ying-Ying Wang, Jung Soo Suk and Ming Yang, doctoral students in the Johns Hopkins Department of Biomedical Engineering; Michael P. Boyle, an associate professor in Pulmonary and Critical Care Medicine at the Johns Hopkins School of Medicine; and Michelle Dawson, an assistant professor at the Georgia Institute of Technology.

This work was supported in part by funding from the National Institutes of Health, a National Center for Research Resources Clinical and Translational Science Award, the Cystic Fibrosis Foundation, the National Science Foundation and a Croucher Foundation Fellowship.

The technology described in the journal article is protected by patents managed by the Johns Hopkins Technology Transfer Office and is licensed exclusively by Kala Pharmaceuticals. Justin Hanes is a paid consultant to Kala Pharmaceuticals, a startup company in which he holds equity, and is a member of its board. The terms of these arrangements are being managed by The Johns Hopkins University in accordance with its conflict-of-interest policies.

(*At the time that this research was published, Hanes had his primary affiliation with the Whiting School of Engineering Department of Chemical and Biomolecular Engineering. Hanes' current primary affiliation is with the Johns Hopkins School of Medicine Department of Ophthalmology.)
