ASML is a world leader in the manufacture of advanced technology systems for the semiconductor industry. The company offers an integrated portfolio for manufacturing complex integrated circuits (also called ICs or chips).
ASML designs, develops, integrates, markets and services advanced systems used by customers – the major global semiconductor manufacturers – to create chips that power a wide array of electronic, communications and information technology products.
With every generation, the complexity of producing integrated circuits with more functionality increases. Semiconductor manufacturers need partners that provide technology and complete process solutions. ASML is committed to providing customers with leading edge technology that is production-ready at the earliest possible date. ASML technology is supported by process solutions, enabling customers to gain and sustain a competitive edge in the marketplace.
ASML’s corporate headquarters is in Veldhoven, the Netherlands. Manufacturing sites and research and development facilities are located in Connecticut, California and the Netherlands. Technology development centers and training facilities are located in Japan, Korea, the Netherlands, Taiwan and the United States. Additionally, ASML provides optimal service to its customers via over 50 sales and service organizations in 16 countries.
Founded in the Netherlands in 1984, the company is publicly traded on Euronext Amsterdam and NASDAQ under the symbol ASML.
