Fast XY Scanning Stage for Optics, Metrology, Microscopy | Voice Coil Linear Motor, Compact, Precise-|PI V-528

https://www.pi-usa.us/en/products/miniature-positioning-stages-motorized-precision/#c61923 V-528 linear stages are motorized with voice coil linear motors to provide friction-less, maintenance-free motion in a compact package. They are available as single axis linear stages and as XY scanner combinations. The V-528 linear stage shown in the video is an XY configuration. It provides 20 mm travel range (5mm and 10mm versions are also available). An integrated optical linear encoder (10nm resolution) is used for position feedback to a compact 2 channel controller.

More information: https://www.pi-usa.us/en/products/miniature-positioning-stages-motorized-precision/#c61923

Run Time - 0:21min

XY Linear Stage, Voice Coil Linear Motor for Scanning, Fast, Precision, V-528 Multi-Axis, XY-Table

Video Credit: PI (Physik Instrumente) LP
